Showing content with the highest reputation since 07/19/2019 in all areas

  1. 2 points
    I have this set and they’re worth every cent. All of the various benefits SD mentions, haven’t yet found a use that this kit didn’t meet.
  2. 2 points
    https://www.j-kenny.com/installation/ also here is the install video. Might help
  3. 2 points
    The Browning A5 is factory designed to auto load. If you saw a Benelli or Stoeger with the auto load feature here in the USA the gun probably had the modification done by MOA Precision, they've had the parts available since early this year (2019). I have one on my RAS Benelli M2. The auto load feature allows you to shoot the gun to empty/bolt locked back, then you can insert shell(s) into the magazine tube and the first shell will automatically exit the mag tube and the action closes and “auto loads” the shell into the chamber. Here is a video demonstrating with my Benelli M2. Benelli Auto Load with MOA Precision parts
  4. 1 point
    The forum has been really slow lately, so I figured I'd try to add some content again. Recently I was contacted by a client to put together the ultimate Benelli M4 with a focus on reliability, and reduced perceived recoil. Cost is not a concern. The main goal was to have a shotgun built for home defense. So, with that said, here is the roughed out plan. The M4 is a 11707 model. It's an older version that has an aluminum trigger frame. The shotgun itself is brand new and never appears to have been fired. This is an 18.5" barreled model. Receiver Upgrades - Loading Port Modifications - GG&G Oversized Bolt Release - TTI Stainless Bolt Handle - FFT Reproduction Handguards Stippled by Tango Arms Stock Upgrades - Benelli M4 OEM Collapsible Stock - IWC MOE QD Sling Mount - Limbsaver 11011 Custom Fit with Noveski Adapter Plate Magazine Tube Assembly - Carriercomp Titanium Full Length Magazine Tube, internals polished - Carriercomp Magazine Follower (Old style with the red plastic indicator) - Carriercomp/Wolff Magazine Spring Trigger Pack - A&S Engineering Trigger Frame - FFT Trigger/Hammer/Disconnector Kit - FFT Shell Elevator - DMW Oversized Safety - Wolff Trigger Pack Spring Kit Sights and Optics - Scalarworks Sync Rail - Trijicon RMR Type 2, RM09 - 1moa dot size - Meprolight Night Sights Weapon Light Package - Surefire M600DF 1500 lumen output. - Impact Weapon Components Benelli M4 Light/Sling Mount - Surefire tailcap modified to remove the shroud Sling - BlueForceGear Padded QD Sling Refinish All parts are to be refinished in NP3 by Robar. Plastics will remain black. Items such as the lamp head on the weapon light will be painted to match the NP3 finish. The Trijicon RMR will be left alone. I received the shotgun on August 6, 2019. By August 7, 2019, the shotgun had been fully disassembled down to the smallest parts. Threaded parts were cleaned up chemically and with a wire wheel to remove any thread locker compound. Cleaning the parts up eats up a lot of time when done right. Even the bolt head is disassembled which is nearly an impossible task without some specialized tools. Getting that roll pin that holds the extractor claw out is almost an impossible task. You need a tiny curved punch in order to tap it out successfully. I disassembled his pistol grip stock so that the sling hardware and the installation screw inside the stock will all be plated in NP3 as well. As expected, the two screws that hold the rear sight in place are destroyed upon removal (the tip of the screw almost always breaks off.) I believe LPA stakes the top of the screw and creates that cupped shape. The nut that holds the front sight in place is a one time use item and will be replaced upon reassembly. This nut cannot be NP3 plated since it has a nylock insert. Small springs are bagged and tagged for reassembly. Some of them are confusing to know the difference by just looking at them. Springs like the one that holds the bolt handle detent and the extractor claw spring can be easily confused with ones from the trigger pack. I'll begin the loading port modifications once the A&S trigger frame arrives. I plan to go high, on the port, but not as high as Briley. I also plan to open the mouth more than Briley typically does. The entire loading port will be dehorned and there will not be a single sharp edge inside the mouth. Mine are all done by hand, so it is a little tedious. The owner supplied the carriercomp components, and the shipment from FFT arrived already. The handguards from FFT were mailed out to Tango Arms this morning. Will update with more as we move forward.
  5. 1 point
    On the stippling, the difference is the classic leaves the thumb shelf area and inside the gills of the handguard unmolested. The complete does everything. I prefer the classic style myself. Tango Arms does a great job and you don’t have any of the plastic coming off in your hand like sand paper. I did note that the stippling is rather sharp when you first get it back, but it seems to soften or the edges get knocked off quickly. I’d send your own set in since their pricing is pretty high to buy a set from them. Kiss the FFT ones for the 922 compliance part. They’re not the best fit compared to the OEM, but I can make it work. I haven’t seen a complete stippling job done on one. The pictures are of the classic. Having a ball mill will speed things up! The limit is the shell stop. It almost looks like Briley trims the pin when they go really deep with this porting. I use a dremel with a pen attachment system so it’s like holding a pencil. Dremel makes an abrasive polishing wheel bit that is excellent for removing aluminum and breaking corners. It’s slow so you don’t loose control. I’ll try to take some progression shots as I go.
  6. 1 point
    After plating the magazine tubes inside and out, I run a jig I made through the inside of the tube. It’ll attach to a drill or to a lathe chuck. It’s sized to spin a bunch of fine steel wool to polish the inside of the magazine tube. Even the spring sounds different when inserting shells. Bunch of parts came in yesterday. Got the Brownells order with the bolt release from GG&G, the IWC light mount and rear sling mount. The collapsible stock showed up from Benelliparts. The Trijicon RMR arrived too. Brownells only had 1 of the 2 rear sight screws in stock. Removal damaged both of the original ones. No ETA on the others arrival. I want to send two to Robar so they’re plated. I have enough of the parts to begin the loading port modifications probably tomorrow. I’ll see about taking some pictures in stages. I do all of mine by hand, so it takes 4-5 hours.
  7. 1 point
    Robar will plate titanium, they just won’t warranty the work. Never had an issue with the plating on any titanium parts.
  8. 1 point
    No problem. Benelli added that washer to the weak sides of the polymer trigger pack. Or perhaps to keep the breech latch pin from wallowing the hole out.
  9. 1 point
    The channelock brand is pretty good. The jaws are rigid so they don’t try to twist on you. They have like 5 different size tips that you can put in them. Angled and different sizes. They flip from inside to outside spawning with the flip of a switch.
  10. 1 point
    Without a good pair of snap ring pliers, they’ll make you question god and the meaning of the universe. The one under the trigger group pin that retains it in to the receiver is a real son of a bitch to get out.
  11. 1 point
    Received the one I ordered on Wednesday today. From Minnesota to Arizona. No need for the washer from the plastic frame.
  12. 1 point
    I've had good luck with them shipping immediately in the past. I ordered one last night for the build, and haven't received a shipping notification yet.
  13. 1 point
    The front sight and rear sight from Meprolights will remain black since you can't plate the sights with their tritium lamps installed. There is a work around for this, but it is costly. You'd have to NP3 plate the OEM sights, then send those out to Tooltech to have Trijicon lamps installed. I think they charge a ridiculous amount, like 250 dollars. The hood of the front sight and the rear sight housing are going to be plated on this one. It will end up looking like this one I did a while back, but the Trijicon RMR's that are nickel boron plated aren't readily available anymore.
  14. 1 point
    I've had good luck with the 8 pellet 00 buck rounds. Might be work getting a box and seeing if that works for you. At least you'll have lots of training rounds to use...
  15. 1 point
    The lifter is a little longer than a standard but not extended like a Taran/C-rums for example. Most of the time that is only done because the loading port isn't opened correctly and people catch thumbs because of technique. The lifter is plated so it has a smooth surface finish to load on
  16. 1 point
    Hi from UK. I have a j Kenny lifter installed in my m2. It works very well. It's two piece design and one additional spring. (similar to MOA but in different location. I also have an moa precision lifer that doesn't cycle rounds at all.
  17. 1 point
    I don't have that, but I can make this work. Thanks.
  18. 1 point
    I can still ghost load* my M2 with the MOA Precision auto load parts. Since the J-Kenny parts use similar design mechanisms I suspect you can still ghost load, but I have no first hand experience with those parts. * My M2 bolt has the usual modification that allows ghost loading
  19. 1 point
    Steve, can you still ghost load with this setup? From your description I would say yes, but would like your first hand experience. Thanks in advance.
  20. 1 point
    I’ve done a lot of Limbsaver pads on collapsible stocks and regular stocks. Now if you cut the stock down, you’ll have to modify the pad to blend in. There have been a few websites outlining the process. I’ve never done one of those. Using a screw was definitely a cost saving measure over copying the factory system that is locked in place by the trigger pack and field serviceable.
  21. 1 point
    The normal functions of the gun remain. You can still load the tube and leave the chamber empty, and you can open the bolt and remove the chambered round without emptying the magazine. If the bolt is closed (regardless of the chamber being empty or loaded) you can load round into the mag tube as in normal operation. The auto load feature allows you to have the gun completely empty (including the mag tube) and the bolt locked open, but now shells can still be inserted into the mag tube.. When you insert the first rounds into the mag tube the first round will then eject into the action and get chambered. This was all developed for competition guns so when the gun is shot dry only one loading technique is needed – just stuff shells into t mag tube and keep going– no need to insert a round into the action, close the bolt, then fill the tube. Whether the “modification” holds up under heavy use / high round count remains to be seen. I have a couple thousand rounds in on my M2 with the MOA Precision parts – so far so good.
  22. 1 point
    If it bypasses most normal operational features ... I suspect this is something that might be more predominantly used specifically for competition. I can understand how some people might say that if it is ideal for competition then it should be a benefit to home defense as well as combat. I would agree with that, but I do appreciate certain normal operational features that the Benelli M4 has.
  23. 1 point
    This J-Kenny Auto Loading Lifter does sound quite interesting, but it leaves me a little bit confused about what manual features it overrides with the Benelli M4. I read their product page on their website, but the info leaves me with more questions and confusion. Does the Auto Loading Lifter not allow the chamber to be clear, the bolt closed and a full magazine tube? What I mean by that is ... I really like that I can chamber my first round and upon racking the charging handle, I can quickly & easily clear the chamber without it automatically ejecting a round from the magazine and allow the bolt to close with an empty chamber. This is where I am left a bit confused as to what this part will disable and/or alter in the way of 'normal' functionality. I think it would be a really good idea for that company to make a thorough video showing two Benelli M4s side by side and demonstrating the original/normal functions vs how it functions using the Auto Loading Lifter.
  24. 1 point
    The Browning A5 (current model and the older “humback” Auto 5 with the 2 piece lifter) are the only shotguns that I know of with the “auto load” feature from the factory. The shell latch design of the Italian influenced guns (current Benelli, Beretta, Stoeger, Franchi) could be adapted, not so with the Remington 1100 or 11/87 action. There is a lot of “that's the way we've always done it” and “not designed here” in the firearms industry...and the Italians seem to have a “our way is the best way” attitude to firearms technology.
  25. 1 point
    I've had good luck with the FFT spring kit. They aren't meant to be lighter or extra power or anything like that. They're produced by Wolff to be a higher quality than OEM springs which tend to take a set. I did not have good luck with the TTI spring kit. I had light primer strikes and ended up removing the springs.
  26. 1 point
    I have the same model, but picked mine up from Gunbroker for about 850. I got really lucky. Love the weapon. Highly recommend.
  27. 1 point
    Just goes to show how much ignorance surrounds us even in a time of such catastrophic events. Oh well. I guess I should have PM'd Rasyad. I'm learning... Blessings...
  28. 1 point
    Here the Stock Retaining Ring is fully seated. I tap on the Stock Retaining Ring with a large flat punch and a small hammer to make sure it is seated fully. 12. Reassemble the weapon Perform a function test of the weapon to ensure that it is functioning properly. Ensure that you properly lubricate the Receiver after degreasing the action. You'll notice a difference when you pull the bolt to the rear if you haven't re-lubricated the weapon. I would recommend testing the safety, trigger and disconnector. That concludes the tutorial on how to disassemble and reassemble the Receiver Extension on the Benelli M4. Hopefully it was clear and will be of use to some users in the future. I will leave the photographs up as long as photobucket remains free. The way the M4 was meant to be.
  29. 1 point
    You're not dense, you're just used to pump shotguns clearly. The idea is that you load a round into the chamber FIRST while the BCG is back and the gun is empty. You then release the BCG, which lets you load additional rounds into the tube. This way, you always have a round in the chamber so you can use it if you need it. It's superior to a pump in that with pumps you have to load rounds into the tube, then pump, in order to accomplish the same thing. The m4 is faster getting a round in the chamber when you have an empty gun. If the bolt is closed, it always allows loading of more shells. The setup is also designed so that you can change the shell that's in the chamber without affecting the shells in the mag tube. It works better than the pump way. The small lever is there to reset the system on command. It allows the BCG to be locked back regardless of how whether the chamber is loaded, not loaded, rounds in the tube, no rounds in the tube, etc. On the next BCG cycle, the bolt will remain locked back, allowing you to manually load or change rounds if you desire. Overall, it gives you much more options and flexibility, not to mention speed, over the standard pump system. It just takes some getting used to, as it is rather different. Once you get good with it, you'll realize how awesome it is.
×
×
